LOW VOLTAGE CONTACT INTERFACE

The LOW VOLTAGE CONTACT INTERFACE can be used to control an electric screen or projector lift by low voltage contact closures and/or via permanent switcher.


Technical specifications

– Power supply 230V a.c.± 10% 50Hz
– Maximum output current 10 Acosφ1,4Acosφ 0.4
– Output voltage on contacts 5/6/7 230V a.c. 50Hz
– Box total dimensions 110x88x50 mm. (WxDxH)
– Terminals’ size 2.5 mm²
– Pulse time minimum 500mSec .
– Satisfies all the technical regulations applicable to the product within the scope of Council Directives 73/23/EEC:

EN 55014-1(2000)+ EN55014-1/A1 (2001)+EN55014-1/A2 (2002)
EN61000-3-2 (2000)
EN61000-3-3 (1995)+ EN61000-3-3/A1 (2001)
EN55014-2(1997)+ EN55014-2/A1 (2001)
EN60335-1 EN60335-2
